5 Port Gigabit (10/100/1000Mbps) Layer-2 Switch fanless, for Desktop
Highlights:
- 5 * 10/100/1000Mbps RJ-45 Nway ports
- Supports MDI/MDI-X auto crossover
- Supports full and half duplex operation on all ports
- Supports back-pressure (half duplex) and flow control (IEEE 802.3x)
- Wire-speed packet filtering and forwarding rate
- Store-and-forward architecture filters fragment & CRC error packets
This device is a powerful and high-performance 10/100/1000Mbps Gigabit Ethernet switch with 5 * 10/100/1000Mbps Gigabit Ethernet ports. It provides a backbone link to your switched workgroup or a server fat-pipe link. With such flexible architecture, users can easily plan the network without bandwidth and media limitation.
The switch is a fully non-blocking architecture and supports every switching port with wire-speed performance. Compared to the shared 10/100/1000Mbps networks, the switch delivers a dedicated 10/100/1000Mbps connection to every attached client with no bandwidth congestion issue. Store-and-forward switching mode promises the low latency plus eliminates all the network errors, including runt and CRC error packets.
The switch provides half and full-duplex capability on all ports to boost bandwidth for servers and power users and is fully compliant with all kinds of network protocols. Moreover, the rich diagnostic LEDs on the front-panel can show the operating status of individual port and whole system. Pre-IEEE 802.3az Energy Efficient Ethernet is also supported to save power consumption.
Technical Details:
| Element | Spezifikation |
| Standard Compliance: | IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX) IEEE802.3ab (1000Base-T) IEEE802.3az |
| Interface: | 5*10/100/1000Mbps RJ-45 ports |
| MAC Address Table: | 2K |
| Jumbo frame: | 9K bytes |
| Buffer Memory: | 128K bytes |
| Temperature: | Operating: 0°C ~ 40°C (32°~104°F)
Storage: -40°C ~ 70°C (-40°~158°F) |
| Humidity: | Operating: 10% ~ 90% RH,
non-condensing Storage: 5% ~ 90% RH, non-condensing |
| LED Indications: | 1*power LED(Power: Green) 5*port LEDs(Link/Act: Green) |
| Power Supply: | External power adapter 5V/1A |
| Dimensions: | 121*75*26 mm |
| Case Material: | Metal |
| Marks: | FCC, CE, VCCi Class A |
