Kuvaus
Shellyn optinen wifi-palovaroitin etähälytyksiä ym. varten.
Toimii CR123A-paristolla. Pariston (mukana) kesto jopa 5 vuotta valmistajan ilmoituksen mukaan, riippuen käyttöolosuhteista ja pariston laadusta.
EN 146004 2005 / AC 2008
Specifications
| Type | Value |
|---|---|
| Physical | |
| Size (DxH): | 86×31 ±0.5 mm / 3.39×1.22 ±0.02 in |
| Weight: | 95 ±1 g / 3.35 ±0.05 oz |
| Mounting: | Ceiling |
| Shell material: | Plastic |
| Color: | White |
| Device lifespan: | 10 years |
| Environmental | |
| Ambient temperature: | -0 °C to 55 °C / 32 °F to 131 °F |
| Humidity: | 30 % to 95 % RH |
| Electrical | |
| Power supply voltage AC: | N/A |
| Power supply voltage DC: | 1x 3 V CR123A/CR17335 battery |
| Battery lifespan: | 5 years (with original battery) |
| Sensors, meters | |
| Smoke sensor: | Photoelectric |
| Radio | |
| RF band: | 2400 – 2495 MHz |
| Max. RF power: | <20 dBm |
| Wi-Fi protocol: | 802.11 b/g/n |
| Wi-Fi Range: | Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth Protocol: | 4.2 |
| Bluetooth Range: | Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| MCU | |
| CPU: | ESP32 |
| Flash: | 4 MB |
| Firmware capabilities | |
| Webhooks (URL actions): | 10 with 2 URLs per hook |
| Scripting: | No |
| MQTT: | Yes |
