Kuvaus
Instantly transform any TV display into a managed digital signage device.
Connects to any HDMI-compatible display
Presents multimedia playlists created in UniFi Connect
PoE in or USB-C adapter power
Note. Does not support Protect camera streaming. Use Protect ViewPort to view Protect camera feeds on an HDMI display.
Technical Specifications
Mechanical
Dimensions
Without mount: 90 x 52 x 31 mm (3.54 x 2.05 x 1.22″)
With mount: 92.1 x 56.3 x 35.7 mm (3.63 x 2.06 x 1.41″)
Weight
Without mount: 163 g (5.75 oz)
With mount: 183 g (6.46 oz)
Hardware
Processor
Quad-core Arm® Cortex®-A55,1.9 GHz
Memory
Storage: 16 GB
DRAM: 2 GB
Power input
PoE, 48V DC, 0.104A
USB-C 5V DC, 1A
Connectivity
(1) GbE RJ45 port
Operating temperature
0 to 40° C (32 to 104° F)
Operating humidity
20 to 90% noncondensing
Certifications
FCC, IC
Software
Management application
UniFi Connect web: Version 1.6.6 and later
UniFi Connect
